Deliver real-time events to authenticated users through Redis PubSub with automatic local fallback, bounded queue protection, and safe subscription lifecycle management.

The Challenge

Building real-time user-targeted event streaming in a horizontally-scaled web application introduces several hard problems:

1. Multi-Node Broadcast: In a standard setup, a WebSocket connection is pinned to a single server process. An event generated on Node A cannot reach a user connected to Node B without a shared backplane.
2. Queue Overrun: Naive in-process queues grow unboundedly when a slow consumer cannot keep up, eventually exhausting memory and crashing the worker.
3. Subscription Leaks: When a WebSocket disconnects, the associated event listener must be cleaned up. Failing to do so results in ghost subscriptions that keep processing and queuing events for connections that no longer exist.

The ZCore Elegance

The StreamManager provides a subscription-based event streaming system. It maintains a per-user mapping of bounded asyncio.Queue instances, routes published events through Redis PubSub to broadcast across all application nodes, and falls back to local in-memory delivery when Redis is unavailable.

from zcore.web.streams import StreamManager
from zcore.web.api_router import ZCoreAPIRoute

stream_manager = StreamManager()

@app.websocket("/ws/events")
async def websocket_endpoint(websocket: WebSocket):
    await websocket.accept()
    user_id = get_authenticated_user_id(websocket)

    # 1. Subscribe via safe context manager
    async with stream_manager.subscription(user_id) as queue:
        while True:
            try:
                event = await asyncio.wait_for(queue.get(), timeout=30)
                await websocket.send_json(event)
            except asyncio.TimeoutError:
                await websocket.send_json({"type": "heartbeat"})

# Publish from any service (any node)
await stream_manager.publish(user_id, {"type": "order_update", "order_id": "123"})

# Single-node only, no cluster support
active_connections: dict[uuid.UUID, list[WebSocket]] = {}

@app.websocket("/ws")
async def ws(websocket: WebSocket):
    user_id = extract_user(websocket)
    active_connections.setdefault(user_id, []).append(websocket)
    try:
        while True:
            data = await websocket.receive_text()
            # No Redis backplane — cannot reach other nodes
    except WebSocketDisconnect:
        # Manual cleanup—easy to forget or mis-handle
        if user_id in active_connections:
            active_connections[user_id].remove(websocket)

Streaming Architecture

Boundaries & Integration

The streaming layer is designed for horizontal scalability and clean lifecycle management.

• Redis PubSub Fallback: The publish method attempts Redis first. If Redis is not configured or the call fails (timeout, connection refused), the event is routed locally via _local_publish. This ensures that streaming works in development without Redis and degrades gracefully in production during Redis outages.
• Dependency Injection Friendly: StreamManager is a plain Python class that can be registered as a singleton in the IoC container. Its publish method can be injected into any service or background task without coupling to the Web layer.
• WebSocket Agnostic: The StreamManager has no dependency on WebSocket or Starlette. It manages asyncio.Queue objects keyed by uuid.UUID. This allows it to be used with custom protocols, SSE (Server-Sent Events), or long-polling implementations.

Under-the-Hood Spec

1. Redis PubSub Backplane with Pattern Subscription

The StreamManager subscribes to the Redis pattern stream:user:* using psubscribe [web/streams.py]. This is a single subscription that matches all user-specific channels. When a message arrives, the handler parses the user ID from the channel name (channel.split(":")[-1]) and forwards the JSON-deserialized payload to the matching local queues.

2. Bounded Queue Overflow Protection

Each user subscription creates an asyncio.Queue(maxsize=100) [web/streams.py]. When _local_publish distributes an event, it calls queue.put_nowait(data). If the queue is full, put_nowait raises asyncio.QueueFull. The handler catches this and removes the overflowing queue from the active list, effectively disconnecting the slowest consumer for that user. This prevents one slow WebSocket from causing memory exhaustion for the entire process.

3. Subscription Context Manager with Guaranteed Cleanup

The subscription(user_id) method is an @asynccontextmanager [web/streams.py]. It calls subscribe on entry (which creates the queue and starts the Redis PubSub listener if needed) and unsubscribe on exit (which removes the queue from the user's list and cancels the PubSub background task if no more active queues exist). This pattern guarantees cleanup even if the WebSocket handler raises an unhandled exception.

4. Background Listener Lifecycle

start_listening initializes the Redis PubSub connection and spawns _listen_to_redis as a background asyncio.Task [web/streams.py]. The task runs until cancelled. In the finally block, it always calls punsubscribe and close() on the PubSub connection, ensuring Redis resources are released. The task is lazily started on the first subscribe call and automatically cancelled in unsubscribe when the last queue is removed.

5. Thread-Safe Queue State with Async Lock

All mutations to the users_queues dictionary are protected by self._lock, an asyncio.Lock [web/streams.py]. This prevents race conditions where a concurrent publish and unsubscribe could modify the same user's queue list simultaneously in an async context.
